Steel frame,powder coating surface
Steel cross brace.
Flip up armrest with PVC Pad
Swing in&out footrest. Optional for the Elevating footrest.
Nylon footplate
8x1 solid PU cast
24inch spoke wheel+PU Tire+ steel push handle
Nylon seat upholstery
Nylon back upholstery
Anti-tipper(option)
Steel front fork
| SPECIFICATION | |||||||||||||||
| Model | Seat width | Total height（mm） | Total Width（mm） | Total Length（mm） | Seat width（mm) | Seat Height（mm） | folid size（mm） | Rear wheel(") | Front wheel（") | Backrest Height（mm） | Max Loading weight（KG) | QTY | Carton Size（mm） | Net weight | Gross weight |
| UN1005 | 12inch | 920 | 530 | 1070 | 310 | 510 | 260 | 24“ | 8” | 440 | 120 | 1 | 810x270x930 | 16.50 | 19.00 |
| UN1005 | 14inch | 920 | 530 | 1070 | 360 | 510 | 260 | 24“ | 8” | 440 | 120 | 1 | 810x270x930 | 17.00 | 19.50 |
| UN1005 | 16inch | 920 | 570 | 1070 | 400 | 510 | 260 | 24“ | 8” | 440 | 120 | 1 | 810x270x930 | 17.50 | 20.00 |
| UN1005 | 18inch | 920 | 630 | 1070 | 460 | 510 | 260 | 24“ | 8” | 440 | 120 | 1 | 810x270x930 | 18.00 | 21.50 |
| UN1005 | 20inch | 920 | 670 | 1070 | 500 | 510 | 260 | 24“ | 8” | 440 | 160 | 1 | 810x270x930 | 18.50 | 22.00 |
| UN1005 | 22inch | 920 | 720 | 1070 | 550 | 510 | 260 | 24“ | 8” | 440 | 180 | 1 | 810x270x930 | 19.00 | 22.50 |
