Aluminum frame,powder coating surface
Aluminum cross brace.
Flip up armrest with PU Pad
Swing in&out footrest. Optional for the Elevating footrest.
Nylon footplate
8x2 solid PU cast
24inch spoke wheel+PU Tire+ aluminum push handle
Nylon seat upholstery
Nylon back upholstery
Anti-tipper(option)
Aluminum front fork
Available seat width: 37cm/40cm/42cm/44cm/46cm/49cm/52cm/55cm
| SPECIFICATION | ||||||||||||||
| Model No | Seat Width mm | Total Length mm | Total Width mm | Total Height mm | Folding Size mm | Seat Depth mm | Back Height mm | Seat Height mm | MOW | Front Wheel | Rear Wheel | N.W | G.W | Carton Size cm |
| UN2015 | 37 | 1100 | 520 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 14.5 | 17 | 81x27x93 |
| UN2015 | 40 | 1100 | 550 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 15 | 17.5 | 81x27x93 |
| UN2015 | 42 | 1100 | 570 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 15.5 | 18.0 | 81x27x93 |
| UN2015 | 44 | 1100 | 590 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 16 | 18.5 | 81x27x93 |
| UN2015 | 45 | 1100 | 610 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 16.5 | 19 | 81x27x93 |
| UN2015 | 49 | 1100 | 640 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 17 | 19.5 | 81x27x93 |
| UN2015 | 52 | 1100 | 670 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 17.5 | 20 | 81x27x93 |
| UN2015 | 55 | 1100 | 700 | 920 | 280 | 400 | 400 | 520 | 120 | 8 | 24 | 18 | 20.5 | 81x27x93 |
