| MODEL | UN5007 |
| N.W. without battery: | 29.5 kg | Seat Width: | 460mm |
| Brushless motor: | 250W*2, DC24V,Maotian Brush Motor | Seat Depth: | 420 mm |
| Lithium Battery: | 24V12AH | Seat to Floor: | 520 mm |
| Controller | Mico Controller， | Backrest Width:高 | 400 mm |
|
| Max. Speed: | 6.0 km/h | Width Between Armrest: | 460 mm |
| Braking distance: | 1.0 m | Armrest to Seat: | 230-290mm |
| Max. Grade Ability: | 15° | Ground clearance: | 190mm |
| Turning Radius: | 85 cm | Wheelbase: | 320 mm |
| Rear Wheel: | 12 inch | Total Length: | 1050mm |
| Front Wheel: | 8 inch | Total Width: | 620 mm |
| Max. safe weight capacity: | 120 kg | Total Height: | 900 mm |
| N.W. of Battery: | 2.0kg/pc | Folding Size: | 800 x350 x 900 mm |
| Max. Driving Distance: | 12 km/1 battery |
|
|
| 24 km/2 batteries |
|
|
| Charger DC Output: | 24V2A | Carton Size: | 810 x 370 x920 mm |
| Charger AC Input: | 100 – 240V, 50/60Hz | Price |
|
| Loading qty | 120PCS/20GP 240PCS/40HC | Price |
|
| Discription | UN5007 |
| Frame | Aluminum frame ,powder coating surface |
| Rear wheel | 12inch Pneumatic tire or PU tire,Gray |
| Front wheel | 8x2 PU,black |
| Seat&Back upholstery | Nylon |
| 6cm seat cushion |
| Footplate | Plastic Footplate |
| Battery | Can load maxinium 2 pieces Lithium batteries for one chair |
| Amrest | Flip up armrest with soft PU pad |
| Including | white /red reflector for power wheelchair |
| Package | bubble foam surround the power wheelchair with good quality carton |
| Seat belt | Nylon seat belt |
| PS | Can put customer's logo to the CE label , back upholstery . |
| Avaliable seat width | 45cm |
